STM32G030F6P6

IC MCU 32BIT 32KB FLASH 20TSSOP

Features

Core: Arm® 32-bit Cortex®-M0+ CPU,frequency up to 64 MHz

-40°C to 85°C operating temperature

MemoriesUp to 64 Kbytes of Flash memory withprotection

8 Kbytes of SRAM with HW parity check

CRC calculation unit

Reset and power management

Voltage range: 2.0 V to 3.6 V

Power-on/Power-down reset (POR/PDR)Low-power modes:Sleep, Stop, Standby

VBAT supply for RTC and backup registers

Clock management

4 to 48 MHz crystal oscillator

32 kHz crystal oscillator with calibration

Internal 16 MHz RC with PLL option-Internal 32 kHz RC oscillator(+5 %)

Up to 44 fast l/Os

-All mappable on external interrupt vectors-Multiple 5 V-tolerant l/Os

5-channel DMA controller with flexible mapping12-bit,0.4 μs ADC (up to 16 ext. channels)-Up to 16-bit with hardware oversamplingConversion range: 0 to 3.6V

8 timers:16-bit for advanced motor control.four 16-bit general-purpose, two watchdogs,SysTick timer

Calendar RTC with alarm and periodic wakeupfrom Stop/Standby

Communication interfaces

Two l2C-bus interfaces supporting Fastmode Plus(1 MMbit's)with extra currentsink, one supporting SMBus/PMBus andwakeup from Stop modeTWo USARTs with master/slavesynchronous SPl; one supporting lS07816interface, LiN,lrDA capability, auto baudrate detection and wakeup feature

Two SPls (32 Mbit/s) with 4-to 16-bitprogrammable bitframe, one multiplexedwith l2S interface

Development support: serial wire debug (SVD)All packages ECOPACK 2 compliant

Introduction

This document provides information on STM32G030x6/x8 microcontrollers, such as description, functional overview, pin assignment and definition, electrical characteristics, packaging, and ordering codes.

Information on memory mapping and control registers is object of reference manual.

Information on Arm®(a) Cortex®-M0+ core is available from the www.arm.com website.

Description

The STM32G030x6/x8 mainstream microcontrollers are based on high-performance Arm® Cortex®-M0+ 32-bit RISC core operating at up to 64 MHz frequency. Offering a high level of integration, they are suitable for a wide range of applications in consumer, industrial and appliance domains and ready for the Internet of Things (IoT) solutions.

The devices incorporate a memory protection unit (MPU), high-speed embedded memories (8 Kbytes of SRAM and up to 64 Kbytes of Flash program memory with read protection, write protection), DMA, an extensive range of system functions, enhanced I/Os, and peripherals. The devices offer standard communication interfaces (two I2Cs, two SPIs / one I2S, and two USARTs), one 12-bit ADC (2.5 MSps) with up to 19 channels, a low-power RTC, an advanced control PWM timer, four general-purpose 16-bit timers, two watchdog timers, and a SysTick timer.

The devices operate within ambient temperatures from -40 to 85°C and with supply voltages from 2.0 V to 3.6 V. Optimized dynamic consumption combined with a comprehensive set of power-saving modes allows the design of low-power applications.

VBAT direct battery input allows keeping RTC and backup registers powered.

The devices come in packages with 8 to 48 pins.
