SN74AUC2G66YZPR

FEATURES

• Available in the Texas Instruments NanoFree™ Package

• Operates at 0.8 V to 2.7 V

• Sub-1-V Operable

• Maxtpd of 0.5 ns at 1.8 V

• LowPowerConsumption, 10 µA at 2.7 V

• High On-Off Output Voltage Ratio

• High Degree of Linearity

• Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II

• ESDPerformance Tested Per JESD 22

– 2000-V Human-Body Model (A114-B, Class II)

– 200-V Machine Model (A115-A)

– 1000-V Charged-Device Model (C101)

DESCRIPTION/ORDERING INFORMATION

This dual analog switch is operational at 0.8-V to 2.7-V VCC, but is designed specifically for 1.1-V to 2.7-V VCC operation.

The SN74AUC2G66 can handle both analog and digital signals. It permits signals with amplitudes of up to 2.7-V (peak) to be transmitted in either direction.

NanoFree™ package technology is a major breakthrough in IC packaging concepts, using the die as the package.

Applications include signal gating, chopping, modulation or demodulation (modem), and signal multiplexing foranalog-to-digital and digital-to-analog conversion systems.
